Technical Specifications

Type Professional Computer
Year
1985
CPU
Intel 8086 @ 10MHz
Co-Processore optional Intel 8087 arithmetic co-processor
RAM 512KB, expandable to 640 KB
ROM 16Kb
VRAM 40 / 80 x 25
Colors 16
Graphic modes
640 x 400 - 640 x 200 - 320 x 200
Sound Beeper
Parallel port
1 X DB25 (Female connector)
Serial port
1 X DB25 (Male connector)
Floppy drive
5.25'' disk-drive (360KB)
Hard drive
20Mb
Monitor Green or yellow phosphore 12" monochrome or
optional color monitor
Supported OS
MS DOS 2.1, Concurrent CP/M 86, UCSD-P, PCOS
